What Is the 3D Relief Process?
3D relief metal badges are made using a special manufacturing process that raises the design above the surface of the badge.
Different heights create depth and dimension, giving the design a more three-dimensional appearance.
Different heights create depth and dimension, giving the design a more three-dimensional appearance.
For example, facial features, animal textures, badge designs, and lettering can all be enhanced with a 3D relief effect, making the details stand out and giving the entire badge a more premium look.
Features of 3D Relief
1. Strong 3D Effect:
The surface of the badge has raised and recessed areas, creating clear layers and depth.
The raised details can also be felt when you touch the badge, giving it a strong visual and tactile effect.
The raised details can also be felt when you touch the badge, giving it a strong visual and tactile effect.
2. Enhanced Metal Finish:
3D relief keeps the natural look of metals such as zinc alloy, copper, and stainless steel.
Finishes such as plating and polishing can further enhance the metal shine, appearance, and durability.
Finishes such as plating and polishing can further enhance the metal shine, appearance, and durability.
3. Rich Details:
3D relief can be used for detailed patterns, textures, and cutout designs.
It works well for people, animals, and other detailed shapes, and can also be combined with finishes such as paint or enamel to enhance the overall look.
It works well for people, animals, and other detailed shapes, and can also be combined with finishes such as paint or enamel to enhance the overall look.
Limitations of 3D Relief
3D relief is not suitable for every design. Lines should generally be at least 0.3mm thick, while the raised height is usually kept between 0.8–2mm and should not exceed 3mm.
Lines that are too thin or raised areas that are too high may affect the final result.
Lines that are too thin or raised areas that are too high may affect the final result.
Fine shadows, realistic faces, very small text, and dense textures are also less suitable for 3D relief, as these details may become less clear.
Because the surface has different heights, paint or enamel is more difficult to apply evenly than on a flat surface.
Therefore, 3D relief is a better choice when you want to highlight depth and metal texture, while other finishing processes may be more suitable when rich and solid colors are the priority.
Therefore, 3D relief is a better choice when you want to highlight depth and metal texture, while other finishing processes may be more suitable when rich and solid colors are the priority.
Applications of 3D Relief Metal Badges
1. Commemorative Badges:
Used to commemorate important events, people, or occasions, such as historical events, sporting events, and company anniversaries.
3D relief can highlight the main elements and add more depth to the design.
3D relief can highlight the main elements and add more depth to the design.
2. Collectible Badges:
The unique 3D design and metal finish make these badges suitable for collectors, especially for vintage-style and limited-edition designs.
3. Brand Badges:
Businesses and organizations can use 3D relief to highlight their logos or brand images, creating a distinctive and professional look.
4. Custom Badges:
Motorcycle badges, custom commemorative badges, and other personalized designs can be made with unique 3D shapes based on your needs.
3D Relief vs. Other Badge Processes
| Process | Effect | 3D Effect | Color | Price | Best For |
|---|---|---|---|---|---|
| 3D Relief | Raised layers and depth | ★★★★★ | ★★☆☆☆ | Higher | People, animals, badges, detailed designs |
| Flat Enamel | Smooth and clear with solid colors | ★☆☆☆☆ | ★★★★★ | Lower | Logos, text, simple designs |
| Soft Enamel | Clear colors with a slightly raised surface | ★★☆☆☆ | ★★★★★ | Lower | Cartoon, brand, and everyday badges |
| Hard Enamel | Smooth and refined | ★★☆☆☆ | ★★★★★ | Medium | Brand and commemorative badges |
| Laser Engraving | Fine lines with a strong metal look | ★★☆☆☆ | ★☆☆☆☆ | Medium | Text, logos, and line-art portraits |
| Printing | Detailed images and a wide range of colors | ★☆☆☆☆ | ★★★★★ | Lower | Photos, complex illustrations, and gradients |
The price of 3D relief products mainly depends on the size, quantity, design complexity, and surface finish. Larger quantities usually have a lower unit cost.
How Can I Customize the Right 3D Relief Product?
3D relief is not limited to badges. You can also customize 3D medals, 3D commemorative coins, and other metal products to bring your design to life.
No matter which product you choose, the process can be simple.
No matter which product you choose, the process can be simple.
1. Share Your Ideas
Start by sharing your artwork, size, quantity, and intended use with the manufacturer.
For example, you may want to create a 3D relief commemorative coin or a portrait badge.
The manufacturer can then help determine the right product and process for your design.
For example, you may want to create a 3D relief commemorative coin or a portrait badge.
The manufacturer can then help determine the right product and process for your design.
2. Confirm the Design and Sample
Once the process is selected, you can review a 3D artwork proof or sample to check the relief height, design details, and overall appearance.
Any necessary changes can be made before production.
Any necessary changes can be made before production.
3. Tips for Choosing a Manufacturer
When choosing a manufacturer, don't focus only on price. Look at their 3D relief samples and confirm their experience with this process.
It is also helpful to ask about sampling, revisions, production time, and the expected final result.
It is also helpful to ask about sampling, revisions, production time, and the expected final result.
Not sure if 3D relief is right for your design? Send us your artwork and our team can help you choose the right process.
Maxemblem · Free Design Support · No Minimum Order · Custom Sizes Available
FAQ
Q1: How High Can 3D Relief Be?
For regular mass production, a raised height of 0.8–2mm is recommended.
Heights above 3mm are generally not recommended, as they can increase the risk of damage, mold issues, and production defects.
Heights above 3mm are generally not recommended, as they can increase the risk of damage, mold issues, and production defects.
Q2: Is My Portrait Suitable for 3D Relief?
Yes, but portraits with clear outlines and moderate details work best.
Photos with complex textures and many small details are less suitable for 3D relief.
UV printing or enamel can be a better choice for these designs.
Photos with complex textures and many small details are less suitable for 3D relief.
UV printing or enamel can be a better choice for these designs.
If you're not sure, send your artwork to [email protected].
With more than 20 years of manufacturing experience, our team can help you choose the right process.
With more than 20 years of manufacturing experience, our team can help you choose the right process.
Q3: Can I Order a Small Quantity of 3D Relief Products?
Yes. Maxemblem has no minimum order quantity, so orders from one piece to 100,000 pieces can be produced.
Q4: Can 3D Relief Be Combined With Enamel?
Yes, but it is best suited to shallow relief with limited enamel filling.
Highly raised areas have more uneven surfaces, making large areas of enamel more difficult to fill evenly.
Highly raised areas have more uneven surfaces, making large areas of enamel more difficult to fill evenly.
Q5: How Long Does 3D Relief Production Take?
From design confirmation to delivery, 3D relief products usually take 2–4 weeks.
For rush orders, let the manufacturer know your deadline when placing the order so they can confirm whether expedited production and shipping are available.
For rush orders, let the manufacturer know your deadline when placing the order so they can confirm whether expedited production and shipping are available.
